Nashco 25mm Top Cross Rail (TCR)

Back to All Products

25mm Top Cross Rail (TCR)

Top Cross Rail Description

N27, 25mm Top Cross Rail is used as the primary channel in concealed suspended ceiling systems. It is suspended from hanging rods by spring hangers and is used to fix furring channels to. By using a primary channel installation is made quicker as far less hangers are need to suspend the Furring Channel.

N27 Top Cross Rail is the most common primary channel used as it will span 1200mm between hanger spans and can be spaced at 1200mm centres when it is used to support a single layer of plasterboard. Made from 0.75bmt material N27 Top Cross Rail can be suspended from a variety of Springhangers including

N60
LPS
N24
N24N
N66

The most common application of Top Cross rail is when it is suspended from N60 or LPS hangers with a large drop from the soffit or purlins above to the requried ceiling height.

Part#

Description

Length

N2736

25mm Top Cross Rail 0.75bmt

3600mm

N2748

25mm Top Cross Rail 0.75bmt

4800mm

N2760

25mm Top Cross Rail 0.75bmt

6000mm
